ETN
Hydraulic buffer H8, ø 50 x 950 mm, height 2.235 mm, hydraulic system with switch for lifts up to 3,7 m/s nominal speed, according to EN 81 - 20/50 : 2014, EN 81 - 1/2 1998+A3; 2009 with operatio...
On request
Delivery time on request - we confirm after your order
Product description
Hydraulic buffer H8, ø 50 x 950 mm, height 2.235 mm, hydraulic system with switch for lifts up to 3,7 m/s nominal speed, according to EN 81 - 20/50 : 2014, EN 81 - 1/2 1998+A3; 2009 with operation bar confirmal to AR 2014/33/EU (valid from 20.04.2016) Load range 500 kg - 4.500 kg
Technical specifications
| Identical in construction to the manufacturer | Henning |
|---|---|
| Piston diameter | 50 mm |
| Tested nominal speeds | 1,00 m/s , 1,30 m/s , 1,60 m/s , 2,00 m/s , 2,50 m/s , 3,20 m/s , 3,70 m/s |
| Load range | 500 kg - 4.500 kg |
| Standard | EN 81-20/50; EN 81-1/2 |
